Laser Pointer : A point of the laser will be provided on the sensor to point the object
Laser Line Generator : Range of the sensor is max. upto 3 mtr. Red visible line of the laser will be generated.
| MODELS | OUTPUT | RANGE |
|---|---|---|
| LP 18 (Dia 18 mm) | Red Laser Point | 20 Meters |
| LX 18 (Dia 18 mm) | Red Laser Cross – 500×500 mm | 20 Meters |
| LL 18 (Dia 18 mm) | Red Laser Line : Length 2 Meters | @ 1 Meter height |
| LL 30 (Dia 30 mm) | Red Laser Bright Line : Length 5 meters | @ 1 Meter height |
| Supply | 10 – 30V DC |
| Range | 20 mtr max |
| Point / Line Size | 4 – 5mm Approx |
| Cable | 2 mtr |
| Housing | Brass |
| Dimensions | 18 D x 75 L mm |
| Supply | 10 – 30V DC |
| Range | At 1 meter Height line length is 2 Meters / 5 Meters |
| Operating Temp. Range | 60 Deg. Celcius ( Max ) |
| Storage Temp. Range | 85 Deg. Celcius ( Max ) . |
| Housing | Brass |
| Dimensions | 18 D x 75 L mm / 30 D x 75 L mm |
